JWF1618(1618E)

Technical highlights

• High speed and efficiency, stability

  • High rotor speed and delivery speed

  • High quality large package yarn

  • New frame structures are simple and stable with high-speed running and lowering suitable for yarn delivery and winding with reduced height

  • Renowned spinning componentswith high efficiency, strong reliabilityand excellent yarn quality


• Good yarn quality and strong adaptability to different varieties

  • The new independent stepper motor for cotton feeding ensures that the fibers are not damaged and avoids defects such as misalignment and spindle deviation.

  • Accurate electrical parameter settings enable milisecond level joint control with joint quality close to the original yarn level.

  • Equipped with an auxiliary yarn suction device, the joint is made at the highest speed to ensure perfect winding quality.

  • The electronic transverse mechanism controlled by the servo system completely eliminates the overlap of yarns.

  • The headstock and endstock of the machine are designed with double impurities, resulting in the lowest negative pressure loss during impurity removal. The utilization rate of excellent fibers is high, and high-quality yarns can be spun.


• Energy Saving

  Double side suction technology

  Exclusive patented front and rear dual side suction technology

  energy-saving by 10% to 15%

  Full inverter closed+oop control system

  Automatically adjust the fan and motor speed to achieve constant negative pressure

  ensuring yam quality and achieving energy-saving goals

  According to actual production testing by customers

  spinning the same variety of yarn at the same speedcan save10% -15% energy.

  Based on the energy consumption of spinning 32 tons of yarn, a 500 spindle equipment:

  save more than 200kW ·h of electricity per day

  and 60,000-70,000 kW·h of electricity per year





• Autoriatic, Intelligent

  • Integrated electromechanical and pneumatic digital connector technology

    When the actual speed of the rotois 100000 revolutions per minute

    90% the success rate of the connector can reach over

  • New efficient single spindle yarn dropping system

    The single spindle yarn dropping time is only 6seconds.Continuous spinning,improving theefficiency of the stopper and reducing the laborintensity of the stopper worker


  • Humanized operation and remote operation and maintenance

    Humanized and operable interface, with single spindle length recording and fault code display functions; Provide remote operation and mainte-nance capabilities to achieve centralized control of group machine data


  • Double sided independent transmission

    Dual conveyor belts transport yarn, with separate start stop on both sides, allowing for simultaneous spinning of two types of yarn throughout the vehicle
